Specification |
|
|
Thermal Core |
|
|
Sensor type |
uncooled |
|
Sensor |
640x512 |
|
Sensor Pixel Size |
12 µm |
|
Optical System |
|
|
Objective lens |
f35 F1.0 |
|
FOV |
12.5°×5° |
|
Human detection distance |
≥ 1500m |
|
Human recognition distance |
≥ 600m |
|
Focus range |
10m～∞ |
|
E-zoom |
1～6X |
|
Eye relief distance |
≥52mm |
|
Diopter setting |
-3～+3 |
|
Display |
|
|
Display type |
OLED |
|
Display resolution |
800×600 PX |
|
Power Supply |
|
|
Battery |
4 * CR123 |
|
Maximum working time |
≥3h |
|
Function |
|
|
Take photos/videos |
Yes |
|
MicroSD card |
32 G |
|
Wi-Fi |
Yes |
|
Electronic compass |
Yes |
|
Weight |
＜ 770 g |
|
Size |
210×87×90 mm |
|
Material of main housing |
Magnesium aluminum alloy |
|
Environment Data |
|
|
Operating temperature |
-40℃～55℃ |
|
Storage temperature |
-55℃～70℃ |
|
Waterproof |
IP67 |
Features
Laser distance measurement
High-performance thermal imaging sensor
Removable battery structure, easy to use
International standard pickup
High-efficiency processor, low power consumption
Long detection distance
Electronic compass
Storage, support for photo and video recording
Wi-Fi, support app connection
